G320ZAN02.2
Product name:
AUO 32 inch 3840x2160 G320ZAN02.2
Product overviews:
This specification applies to the Color Active Matrix Liquid Crystal Display G320ZAN02.2 composed of a TFT-LCD display, a driver and power supply circuit, and a LED backlight system. The screen format is intended to support the UHD (3840(H)x2160(V)) screen and 1.07B colors. All input signals are eDP interface compatible. LED driving board for backlight unit is included in G320ZAN02.2.
Supply Status:
Steady supply.
| Brand: | AUO |
| Model P/N: | G320ZAN02.2 |
| Diagonal Size: | 32 inch |
| Pixels: | 3840x2160 |
| Pixel Pitch(mm): | 0.1845 x 0.1845 mm |
| Interface Type: | eDP |
| Luminance: | 850 cd/m² |
| Viewing Angle: | 89/89/89/89 (Typ.) |
| Active Area(mm): | 708.48 (H) x 398.52 (V) mm |
| Physical Size(mm): | 727.3 (H) x 424.5 (V) x 20.48 (D) (Typ) |
| Contrast Ratio: | 1800:1 |
| Response Time: | 22 (Typ.)(Tr+Td) (ms) |
| Work Mode: | Normally Black, AHVA |
| Surface Treatment: | Anti-Glare treatment |
| Color Depth: | 10bit(True 10) |
| Backlight: | WLED,30K hours withLED |
| Input Voltage: | 12.0V (Typ.) |
| Storage Temp: | -20 ~ 60 °C |
| Operating Temp: | 0 ~ 50 °C |
| Touchscreen: | without |
| Net Weight: | 4.63Kgs (Typ.) |
| Package: | Max capacity:4 pcs TFT-LCD module per carton |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
