Product model: LH320YX012A
Product name:
LEEHON 320inch 1920(RGB)×1080, FHD,60Hz LH320YX012A
Product overviews:
LH320YX012A is a color active matrix TFT LCD MDL using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This open cell has a 31.51 inch diagonally measured active area with FHD resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this open cell can display 16.7M colors. The TFT-LCD panel used for this open cell is adapted for a low reflection and higher color type.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH320YX012A |
| Diagonal Size: | 320inch |
| Pixels: | 1920(RGB)×1080, FHD,60Hz |
| Active Area(mm): | 698.4×392.85 mm |
| Physical Size(mm): | 730 * 425 * 16 mm |
| Luminance: | ≥500 cd/m ² |
| Contrast Ratio: | 1200:1 (Typ.) |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 89/89 (Typ.)(CR≥ 10) |
| Work Mode: | ADSDS， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 8 (Typ.)(G to G) ms |
| Color Depth: | |
| Interface Type: | Capacitive touch, 10 point touch, with RC filtering circuit and electromagnetic shielding function (optional) |
| Net Weight: | TBD |
| Operating Voltage: | 12V (Typ.) |
| Temperature: | Working temperature: -20~55 ° C; Storage temperature: -40~65 ° C |
| Electromagnetic Compatibility: | 250 mesh irregular omentum |
| Power consumption: | 57.6 W |
| Touch: | Capacitive touch, 10 point touch, with RC filtering circuit and electromagnetic shielding function (optional) |
| Heated glass: | Heating power consumption specified by the customer, with temperature control (optional) |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
