P1400FHF1MA00
Product name:
TIANMA 14 inch 1920×1080 P1400FHF1MA00
Product overviews:
The P1400FHF1MA00, a 14 inch a-Si TFT-LCD module by Tianma, is designed for high performance and reliability. It features a Full HD (FHD) resolution of 1920x1080 with an aspect ratio of 16:9, providing crisp and clear visuals. The display area measures 309.312mm x 173.988mm, while the overall dimensions are 315.31mm x 184.49mm x 8.5mm, ensuring a compact design suitable for various applications. Equipped with WLED backlighting, it offers a bright and uniform illumination, and the inclusion of an LED driver simplifies integration. The module operates within a temperature range of -20°C to 70°C, making it suitable for a wide range of environments. With a typical refresh rate of 60Hz, this panel delivers smooth motion without flicker. The interface uses a 2-channel, 8-bit LVDS signal, totaling 30 pins, and operates at a typical voltage of 5.0V. This robust display solution is ideal for industrial, medical, and consumer electronics where high-quality visual output is essential.
Supply Status:
Steady supply.
| Brand: | TIANMA |
| Model P/N: | P1400FHF1MA00 |
| Diagonal Size: | 14 inch |
| Pixels: | 1920×1080 |
| Pixel Pitch(mm): | 0.1611*0.1611 mm |
| Interface Type: | LVDS |
| Luminance: | 800 cd/m² |
| Viewing Angle: | 88/88/88/88 (Typ.)(CR≥10) |
| Active Area(mm): | 309.312 x 173.988 mm |
| Physical Size(mm): | 315.31×184.49×3.11 mm |
| Contrast Ratio: | 2200:1 |
| Response Time: | 35 (Typ.)(Tr+Td) ms |
| Work Mode: | SFT, Normally Black |
| Surface Treatment: | Anti-Glare |
| Color Depth: | 16.7 M |
| Backlight: | WLED , without LED Driver |
| Input Voltage: | 5V |
| Storage Temp: | -30 ~ 80 °C |
| Operating Temp: | -20 ~ 70 °C |
| Touchscreen: | without |
| Net Weight: | TBD |
| Package: | / |
