LH140LX029A
Product name:
LEEHON 140inch 1920(RGB)×1080, FHD, 157PPI LH140LX029A
Product overviews:
LH140LX029A is a color active matrix TFT LCD module using IGZO TFT‘s (Thin Film Transistors) as an active switching devices. This module has a 14.0 inch diagonally
measured active area with Full-HD resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical stripe and this module can display 16.2M(6bit+FRC) colors and color gamut 72%. The TFT-LCD panel used for this module is a low reflection and higher color type. Therefore, this module is suitable for Notebook PC. The LED driver for backlight driving is built in this model. All input signals are eDP1.4 interface compatible.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH140LX029A |
| Diagonal Size: | 140inch |
| Pixels: | 1920(RGB)×1080, FHD, 157PPI |
| Active Area(mm): | 309.31×173.99 mm |
| Physical Size(mm): | 332.6 × 218.5 × 4.25 mm |
| Luminance: | ≥ 600 cd/m ² |
| Contrast Ratio: | 1500：1 |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 85/85/85/85 (Typ.)(CR> 10) |
| Work Mode: | ADS， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 35 (Typ.)(Tr+Td) ms |
| Color Depth: | |
| Interface Type: | EDP (2 Lanes), eDP1.4, HBR1 (2.7G/lane), 30 pins, terminals |
| Net Weight: | TBD |
| Operating Voltage: | 3.3V (Typ.) |
| Temperature: | Working temperature: -25~55 ° C; Storage temperature: -45~70 ° C |
| Electromagnetic Compatibility: | 250 mesh irregular mesh membrane, shielding effectiveness ≥ 40 |
| Power consumption: | 6.3 W |
| Touch: | Capacitive touch, 10 point touch, with RC filtering circuit and electromagnetic shielding function (optional) |
| Heated glass: | Heating power consumption specified by the customer, with temperature control (optional) |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
