TM035KDGP01
Product name:
TIANMA 3.5 inch 320×240 TM035KDGP01
Product overviews:
The TM035KDGP01 is a 3.5-inch TFT LCD display by Tianma, featuring a resolution of 320x240 pixels and a brightness of 350 nits. Designed for a variety of applications, it uses SFT (Super Fine TFT) technology for improved viewing angles and color reproduction. The display supports a standard RGB interface and is suitable for use in portable devices, industrial controls, and other embedded systems.
Supply Status:
Steady supply.
| Brand: | TIANMA |
| Model P/N: | TM035KDGP01 |
| Diagonal Size: | 3.5 inch |
| Pixels: | 320×240 |
| Pixel Pitch(mm): | 0.219 x 0.219 mm |
| Interface Type: | RGB |
| Luminance: | 350 cd/m² |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) |
| Active Area(mm): | 70.08 x 52.56 mm |
| Physical Size(mm): | 76.9x63.9x3.15 mm |
| Contrast Ratio: | 800:1 |
| Response Time: | 25 (Typ.)(Tr+Td) ms |
| Work Mode: | Normally Black |
| Surface Treatment: | HC |
| Color Depth: | 16.7M，60% NTSC |
| Backlight: | WLED , 20K hours |
| Input Voltage: | 3.3V |
| Storage Temp: | -30 ~ 80 °C |
| Operating Temp: | -20 ~ 70 °C |
| Touchscreen: | without |
| Net Weight: | 31g |
| Package: | / |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
