TCG121WXLRFVNN-AN40
Product name:
KYOCERA 12.1 inch 1280x800 TCG121WXLRFVNN-AN40
Product overviews:
TCG121WXLRFVNN-AN40 is a 12.1-inch LCD module product launched by Kyocera Display Co., Ltd. (Kyocera) using a-Si TFT-LCD technology. It is equipped with WLED backlight, LED driver backlight driver, and touch free. As an AWV, normally black display, and transmissive LCD module product, TCG121WXLRFVNN-AN40 can provide a display brightness of 1500 cd/m ² with a transmission contrast ratio of 750:1, as well as a viewing angle of 85/85/85 (Typ.) (CR ≥ 10) (L/R/U/D). The optimal viewing angle is full view angle, and its response time is 18/12 (Typ.) (Tr/Td) ms.
Supply Status:
Steady supply.
| Brand: | KYOCERA |
| Model P/N: | TCG121WXLRFVNN-AN40 |
| Diagonal Size: | 12.1 inch |
| Pixels: | 1280x800 |
| Pixel Pitch(mm): | 0.204×0.204 mm |
| Interface Type: | LVDS |
| Luminance: | 1500 cd/m² |
| Viewing Angle: | 85/85/85/85 (Typ.) |
| Active Area(mm): | 261.12×163.2 mm |
| Physical Size(mm): | 283×185.1×10.5mm |
| Contrast Ratio: | 750:1 |
| Response Time: | 18/12 (Typ.)(Tr/Td) ms |
| Work Mode: | AWV, Normally Black |
| Surface Treatment: | Anti-Glare |
| Color Depth: | 16.7M (8-bit) |
| Backlight: | WLED,50K hours withLED |
| Input Voltage: | 3.3V (Typ.) |
| Storage Temp: | -30 ~ 80 °C |
| Operating Temp: | -30 ~ 80 °C |
| Touchscreen: | without |
| Net Weight: | 600g |
| Package: | - |
