TM060RDH01
Product name:
TIANMA 6 inch 800×480 TM060RDH01
Product overviews:
The TM060RDH01 is a 6.0-inch a-Si TFT-LCD display from Shanghai Tianma Micro-Electronics, featuring an 800x480 WVGA resolution. This display offers a brightness of 400 cd/m², providing good visibility even in well-lit environments. It includes features such as gamma correction reference voltage settings, which are crucial for accurate color representation. The TM060RDH01 supports a standard RGB and TTL interface, making it easy to integrate into various applications, including portable devices, industrial controls, and other embedded systems. Its robust design and technical specifications make it a versatile solution for projects requiring a reliable and visually clear display.
Supply Status:
Steady supply.
| Brand: | TIANMA |
| Model P/N: | TM060RDH01 |
| Diagonal Size: | 6 inch |
| Pixels: | 800×480 |
| Pixel Pitch(mm): | 0.1665x0.1538 mm |
| Interface Type: | TTL |
| Luminance: | 400 cd/m² |
| Viewing Angle: | 70/70/60/70 (Typ.)(CR≥10) |
| Active Area(mm): | 133.20x73.80 mm |
| Physical Size(mm): | 145.50x87.80x5.40 mm |
| Contrast Ratio: | 500:1 |
| Response Time: | 20/30 (Typ./Max.)(Tr+Td) ms |
| Work Mode: | TM with Normally White |
| Surface Treatment: | Anti Glare |
| Color Depth: | 262K/16.2M , 50% NTSC |
| Backlight: | WLED , 20K hours , without LED Driver |
| Input Voltage: | 3.3V |
| Storage Temp: | -30 ~ 80 °C |
| Operating Temp: | -20 ~ 70 °C |
| Touchscreen: | without |
| Net Weight: | TBD |
| Package: | / |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
