Product model: LH270BW001A
Product name:
LEEHON 270inch 1920(RGB)×1080, FHD, 81PPI LH270BW001A
Product overviews:
LH270BW001A is a color active matrix TFT LCD module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 27 inch
diagonally measured active area with FHD resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a low reflection and higher color type.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH270BW001A |
| Diagonal Size: | 270inch |
| Pixels: | 1920(RGB)×1080, FHD, 81PPI |
| Active Area(mm): | 597.888×336.312 mm |
| Physical Size(mm): | 644 × 388 × 13.8 mm |
| Luminance: | ≥300 cd/m ² |
| Contrast Ratio: | 1000:1 (Typ.) |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 89/89/89/89(typ.) |
| Work Mode: | ADS， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 14 (Typ.)(G to G) ms |
| Color Depth: | |
| Interface Type: | 30 pins LVDS (2 ch, 8-bit), terminals |
| Net Weight: | 3910g |
| Operating Voltage: | 5V (Typ.) |
| Temperature: | Working temperature: -25~55 ° C; Storage temperature: -40~70 ° C |
| Electromagnetic Compatibility: | 100 mesh shielding film |
| Power consumption: | 24.3 W |
| Touch: | Capacitive touch, 10 point touch, with RC filtering circuit and electromagnetic shielding function (optional) |
| Heated glass: | Heating power consumption specified by the customer, with temperature control (optional) |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
