LH185NL030A
Product name:
LEEHON 185inch 1920(RGB)×1080 FHD 119PPI LH185NL030A
Product overviews:
LH185NL030A is a color active matrix TFT LCD module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 18.5 inch diagonally measured active area with FHD resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7 M colors.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH185NL030A |
| Diagonal Size: | 185inch |
| Pixels: | 1920(RGB)×1080 FHD 119PPI |
| Active Area(mm): | 408.96×230.04 mm |
| Physical Size(mm): | 430.40*254.6*15.80 mm |
| Luminance: | ≥300 cd/m ² |
| Contrast Ratio: | 1000:1 (Typ.) |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 85/85/85/85 (Typ.)(CR>10) |
| Work Mode: | ADS， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 30 (Typ.)(Tr+Td) ms |
| Color Depth: | |
| Interface Type: | 30 pins LVDS (2 ch, 8-bit), terminals |
| Net Weight: | 2350g |
| Operating Voltage: | 5V (Typ.) |
| Temperature: | Working temperature: -40~60 ° C; Storage temperature: -45~70 ° C |
| Electromagnetic Compatibility: | 250 mesh irregular shielding film |
| Power consumption: | 15W |
| Touch: | COB scheme |
| Heated glass: | 40-60W |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
