Product model: LH173HX042A
Product name:
LEEHON 173inch 1920*1080 LH173HX042A
Product overviews:
LH173HX042A is a color active matrix TFT LCD module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 17.3 inch diagonally measured active area with Full-HD resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M(8bit) colors and color gamut 45%. The TFT-LCD panel used for this module is a low reflection and higher color type. Therefore, this module is suitable for Notebook PC. The LED driver for back-light driving is built in this model. All input signals are eDP1.2 interface compatible.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH173HX042A |
| Diagonal Size: | 173inch |
| Pixels: | 1920*1080 |
| Active Area(mm): | 381.888×214.812 mm |
| Physical Size(mm): | 402.62*244.13*6.52 mm |
| Luminance: | 300 cd/m ² |
| Contrast Ratio: | 800:1 (Typ.) |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 85/85/85/85 (Typ.)(CR> 10) |
| Work Mode: | ADS， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 16 (Typ.)(Tr+Td) ms |
| Color Depth: | |
| Interface Type: | 30 pins eDP (2 Lanes), eDP1.2, HBR1 (2.7G/lane), terminals |
| Net Weight: | 1100g |
| Operating Voltage: | 3.3V (Typ.) |
| Temperature: | Working temperature: -20~55 ° C; Storage temperature: -50~65° C |
| Electromagnetic Compatibility: | 150 mesh shielding film with shielding effectiveness ≥ 40dB |
| Power consumption: | 7.2 W |
| Touch: | Capacitive touch, 10 point touch, with RC filtering circuit and electromagnetic shielding function (optional) |
| Heated glass: | Heating power consumption specified by the customer, with temperature control (optional) |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
