LH173DY059A
Product name:
LEEHON 173inch 1920(RGB)×1080, FHD, 127PPI LH173DY059A
Product overviews:
LH173DY059A is a color active matrix TFT LCD module using amorphous silicon TFT‘s (Thin Film Transistors) as an active switching devices. This module has a 17. 3 inch diagonally measured active area with SVGA resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH173DY059A |
| Diagonal Size: | 173inch |
| Pixels: | 1920(RGB)×1080, FHD, 127PPI |
| Active Area(mm): | 381.89×214.81 mm |
| Physical Size(mm): | 397.90 * 238.45 * 10.3 mm |
| Luminance: | ≥ 700 cd/m ² |
| Contrast Ratio: | 1100:1 (Typ.) (TM) |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 85/85/85/85 (Min)(CR≥ 10) |
| Work Mode: | ADS， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 16 (Typ.)(Tr+Td) ms |
| Color Depth: | |
| Interface Type: | EDP (2 Lanes), eDP1.2, 45 pins, terminals |
| Net Weight: | 1420g |
| Operating Voltage: | 3.3V (Typ.) |
| Temperature: | Working temperature: -40~60 ° C; Storage temperature: -55~70 ° C |
| Electromagnetic Compatibility: | Meet the eight requirements of 151B Army |
| Power consumption: | 22.5 W |
| Touch: | Capacitive touch, 10 point touch, with RC filtering circuit and electromagnetic shielding function (optional) |
| Heated glass: | Heating power consumption specified by the customer, with temperature control (optional) |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
