LH156HX120A
Product name:
LEEHON 156inch 1920(RGB)×1080 FHD 141PPI LH156HX120A
Product overviews:
Color LCD module LH156HX120A is composed of the amorphous silicon thin film transistor liquid crystal display (a-Si TFT LCD) panel structure with driver LSIs for driving the TFT (Thin Film Transistor) array and a backlight. The a-Si TFT LCD panel structure is injected liquid crystal material into a narrow gap between the TFT array glass substrate and a color-filter glass substrate. Color (Red, Green, Blue) data signals from a host system (e.g. signal generator, etc.) are modulated into best form for active matrix system by a signal processing board, and sent to the driver LSIs which drive the individual TFT arrays. The TFT array as an electro-optical switch regulates the amount of transmitted light from the backlight assembly, when it is controlled by data signals. Color images are created by regulating the amount of transmitted light through the TFT array of red, green and blue dots.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH156HX120A |
| Diagonal Size: | 156inch |
| Pixels: | 1920(RGB)×1080 FHD 141PPI |
| Active Area(mm): | 344.16×193.59 mm |
| Physical Size(mm): | 365 × 216 × 11.75 mm |
| Luminance: | ≥ 1000 cd/m ² |
| Contrast Ratio: | 1000:1 (Typ.) |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 88/88/88/88 (Typ.)(CR> 10) |
| Work Mode: | UA-SFT， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 12/13 (Typ.)(Tr/Td) ms |
| Color Depth: | |
| Interface Type: | LVDS (2 ch, 8-bit), terminal, 30 pins |
| Net Weight: | TBD |
| Operating Voltage: | 3.3V (Typ.) |
| Temperature: | Working temperature: -40~60 ° C; Storage temperature: -40~70 ° C |
| Electromagnetic Compatibility: | 250 mesh irregular omentum |
| Power consumption: | 28.8 W |
| Touch: | Capacitive touch, 10 point touch, with RC filtering circuit and electromagnetic shielding function (optional) |
| Heated glass: | Heating power consumption specified by the customer, with temperature control (optional) |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
