LH101NL050B
Product name:
LEEHON 101inch 1920(RGB)×1200, WUXGA, 225PPI LH101NL050B
Product overviews:
LH101NL050B is a color active matrix TFT LCD module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 10.1 inch diagonally measured active area with resolutions (1920 horizontal by 1200 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.2M colors.
Supply Status:
Steady supply.
| Brand: | LEEHON |
| Model P/N: | LH101NL050B |
| Diagonal Size: | 101inch |
| Pixels: | 1920(RGB)×1200, WUXGA, 225PPI |
| Active Area(mm): | 216.576×135.36 mm |
| Physical Size(mm): | 244.75 × 173.10 × 5.6 mm |
| Luminance: | ≥1200 cd/m ² |
| Contrast Ratio: | 1000 : 1 (Typ.) |
| Best Viewing Angle: | Full perspective |
| Viewing Angle: | 85/85/85/85 (Typ.)(CR> 10) |
| Work Mode: | HADS， Constant black display, transparent |
| Refresh rate: | 60Hz |
| Response Time: | 30 (Typ.)(Tr+Td) ms |
| Color Depth: | |
| Interface Type: | MIPI (4 data lanes), eDP1.4, HBR1 (2.7G/lane), terminal, 30 pins |
| Net Weight: | 336g |
| Operating Voltage: | 3.3V (Typ.) |
| Temperature: | Working temperature: -40~60 ° C; Storage temperature: -40~70 ° C |
| Electromagnetic Compatibility: | 250 mesh irregular omentum |
| Power consumption: | 8.4 W |
| Touch: | TB56Z-JUC2 |
| Heated glass: | Heating power consumption (15-20) W, power supply voltage 6-8V |
| Aviation plug interface: |
The following accessories are available for you to choose!
Specifications are provided to refer to detailed parameters and circuit settings, and 3D documents are used for structural design. If you are still unsure, we can provide original technical support.
